TECHNICAL DATA SHEET

Available sizes: M, L, XL, XXL.

M (1.64 - 1.79 meters)
L (1.75 - 1.88 meters)
XL (1.84 - 1.95 meters)
XXL (1.92 - 2.00 meters)

Wheel size: 27.5"/584 mm
Frame: 27.5″, 6061 alloy, external battery
Fork: SR SUNTOUR XCT30 HLO, spring, 100 mm
Motor: Yamaha PW-TE, 250 W, 60 Nm
Battery: Yamaha DT500, 500Wh, 36V
Display: Yamaha Display A, LCD display, micro USB
Charger: Yamaha fast charger, 4 A
Display: Yamaha Display A, LCD display, micro USB
Switch mode : integrated into the screen
Front brake: Tektro HD-M275, 2-piston, hydraulic disc brake
Rear brake: Tektro HD-M275, 2-piston, hydraulic disc brake
Front derailleur: Tektro RD-T350, 9-speed
Switch selection mechanism: Tektro SL-M350R
Cassette: Tektro CS-M350, 11-46 T
Channel: KMC Z9
Chainring: R Raymon, 38T
Crankset: Wheeltop, forged aluminum, JIS
Front wheel: Rim: Mach 1 TRAXX, eyelet, tubeless ready / Hub: R Raymon DB600F, 6 holes, 9×100 mm, quick-release wrench
Rear wheel: Rim: Mach 1 TRAXX, eyelet, tubeless ready / Hub: R Raymon DB600R, 6 holes, 9×135 mm, quick-release wrench, HG
Tires: Mitas Ocelot, 60-584, 27.5 x 2.35
Radius: Mach1, stainless steel
Stem: R Raymon 31.8, 7°, Ahead
Handlebar: R Raymon Riser 31.8mm, 720mm, Sweep: 6°, Rise: 15mm
Grips: R Raymon MTB, screw-on grips
Saddle: R Raymon MTB
Seatpost: R Raymon, 31.6 mm, 350 mm, patent
Pedals: R Raymon, plastic
Weight: 22.4 kg
Maximum permissible weight: 130 kg
